Weatherproof & Waterproof NPT Cable Glands (Cord Grips | Cable Grips) IP68 Stainless Steel Type 304, 316, 316L

Name: Weatherproof amp Waterproof NPT Cable Glands Cord Grips Cable Grips IP68 Stainless Steel Type 304 316 316L
Brand: Sino Cable Gland Factory
Price: 1 USD

Quality Weatherproof & Waterproof NPT Cable Glands (Cord Grips | Cable Grips) IP68 Stainless Steel Type 304, 316, 316L wholesale

Brand Name : Sino Cable Gland Factory

Model Number : NPT series

Certification : CE, SGS, RoHS, IP68, IP69K

Place of Origin : Zhejiang, China

MOQ : 100 pieces

Price : lowest prices from direct factory

Payment Terms : T/T, L/C, Western union, Cash

Supply Ability : 1,000,000 pieces per month

Delivery Time : normally 8-12 days

Packaging Details : export packing (special packing is also available on request)

Product name : Stainless Steel Cable Glands Cord Grip Fittings Connectors

Model : NPT1/4" ~ NPT3"

Material : Stainless Steel SS304, SS304L, SS316, SS316L

Plastic insert : UL-certified PA6

Sealing parts : NBR, EPDM, FKM, SILICONE rubber

Surface treatment : Polishing

Protection : IP68

Metric : ANSI/ASME B 1. 20. 1

Advantages : Resistant to liquid and weather, anti-aging, flameproof

Contact Now

Applications areas:

With advantages of high impact resistance, wide clamping range, optimum strain relief, high sealing performance & resistant to sunlight, Weatherproof & Waterproof NPT Cable Glands (Cord Grips | Cable Grips) IP68 Stainless Steel Type 304, 316, 316L have the ability of chemical resistance, corrosion resistance and anti-aging, and it also has the ability of high breaking tensile strength, high tenacity and optimum water resistance. Besides, such cable glands from our factory have long service time.

It is anti-salt, anti-dust, its resistance to acid, base, alcohol, oil, grease and common solvent is very strong. Besides, it does well in insulation, it is secure and safe.

They are popular in the application of electrical and electronic technologies, telecommunications, wireless networking ODUs, automatic control, power supplies, switches, motors, distribution boxes, solar PV modules, Inverters, lightings, displays, traffics, signals, surveillance cameras, plant engineerings, machineries, meters and instruments, etc.

Product details:

No.	Item	Description
1	Place of origin:	Zhejiang, China
2	Manufacturer:	Yueqing Sino Cable Gland Factory
3	Product name:	Weatherproof & Waterproof NPT Cable Glands (Cord Grips \| Cable Grips) IP68 Stainless Steel Type 304, 316, 316L
4	Models:	NPT1/4, NPT3/8, NPT1/2, NPT3/4, NP1, NPT1-1/4, NPT1-1/2, NPT2, NPT2-1/2, NPT3
5	Material:	Stainless Steel SS304, SS304L, SS316 or SS316L
6	Seal & O-ring:	Buna-N (also available in EPDM rubber, rubber or Silicone rubber)
7	Plastic insert:	polyamide 66 approved by UL, 94V-2 (also available in 94V-0)
8	Surface treatment:	polishing
9	Colors:	metallic silver
10	Features:	provide excellent strain relief for cables and provide IP68 protection against the ingress of dirt, water and other liquids. anti-oxidation, resistant to aging and corrosion, resistant to seawater, oil, weak acid, weak alkaline, alcohol, solvents, etc.
11	Certifications:	CE, ROHS, SGS, IP68
12	Protection:	IP68 (when the cable diameter is within the clamping range and mount the O-ring)
13	Thread standard:	according to ANSI/ASME B 1. 20. 1
14	Working temperature:	static:-40 ℃ to 100 ℃, short-term:120 ℃. Dynamic:-20 ℃ to 80 ℃, short-term:100 ℃ (nylon part & rubber part)
14	Working temperature:	non-magnetic, temperature range: -196 ℃ ~ 800 ℃ (stainless steel part)
15	Quality grade:	high quality
16	OEM services:	available (special cable glands can be customized as per customer's original samples or technical drawings)
17	Supply capability:	100,000 pieces per month
18	Price advantage:	lowest prices from direct factory
19	Minimum quantity:	negotiable
20	Sample availability:	yes, free samples are available upon request
21	Delivery time:	7-10 days after confirmation of orders
22	Payment terms:	T/T, Western Union, Paypal, Cash, L/C at sight
23	Delivery terms:	EXW, FCA, FOB, CIF, CNF
24	Shipping ways:	by courier (EMS, TNT, DHL, UPS or FEDEX)
		by air (Shanghai / Ningbo)
		by sea (Shanghai / Ningbo)
25	Export packing:	100 pieces per bag, 50 pieces per bag (bag + neutral label or OEM label)
		100 pieces per box, 50 pieces per box (white box or OEM color box)
		other special packings also available on request
